Cat.6 UTP 180° Quick Solution /w Shutter – Keystone Jack

CAT 6 UTP 180° Keystone Jack is designed with easy

installation in mind and compatible with CAT 6 component

performance (ANSI/TIA-568-C.2 Category 6).

Compatible with SYSThames One Punch Tool which can

reduce jack termination time and save time up to 8 times

compared to traditional termination.cat6_utp_180_shutter

Category: Keystone Jack Product ID: 8709

Description

CAT 6 UTP 180° Keystone Jack is designed with easy

installation in mind and compatible with CAT 6 component

performance (ANSI/TIA-568-C.2 Category 6).

Compatible with SYSThames One Punch Tool which can

reduce jack termination time and save time up to 8 times

compared to traditional termination.

Features	Front Connection Spring Wire: Phosphor Bronze Alloy. Plated with 50 micro-inch of Gold over 70-100 micro-inch of Nickel IDC Material: Phosphor Bronze Alloy with 10 micro-inch 100% Tin Alloy Can terminate stranded or solid 22~24AWG wires. T568A/B wiring
Applications	Voice; T1; ISDN 10GBASE-T 16Mbps Token Ring (IEEE802.5) 100VG-AnyLAN (IEEE802.12) 100BASE-T Ethernet (IEEE802.3) 155/622Mbps 1.2/2.4 Gbps ATM 1000Mbps Gigabit Ethernet 550MHz Broadband Video
Standards	UL 1863 Safety listed UL 94V-0 Fire Retardant Plastic ANSI/TIA Standard 568-2.D ISO/IEC 11801 2. Ed. CENELEC EN 50173
Available Colours	1716-12012 – White 1716-22012- Blue 1716-32012- Yellow
